Metasol MS

Metasol Contactor & Overload Relay

Compact & easy connection & high performance and long electrical life & greater environmental immunity sealed structure which improves its safety features

Get in Touch

Features

Specification

Download

Features

High Performance

Reliable in the system: Type ∥ coordination
Perfect system with peripheral devices
No arc exposure via sealed structures

User Convenience

One-touch connection with Din Rail
Simple wiring with adapter, reversing wire set
4-terminal type: Easy wiring of operation coil
Module type screw terminal
Interlocking unit with built-in auxiliary contacts (2NO built-in)

Specification

Type		AC-1	AC-3
		A	220/240V		380/440V		500/550V		690V		1000V
		A	KW	A	KW	A	KW	A	KW	A	KW	A
18AF	MC-6a	25	2.2	9	3	7	3	6	3	4	–	–
	MC-9a	25	2.5	11	4	9	4	7	4	5	–	–
	MC-12a	25	3.5	13	5.5	12	7.5	12	7.5	9	–	–
	MC-18a	32	4.5	18	7.5	18	7.5	13	7.5	9	–	–
22AF	MC-9b	25	2.5	11	4	9	4	7	4	6	–	–
	MC-12b	27	3.5	13	5.5	12	7.5	12	7.5	9	–	–
	MC-18b	32	4.5	18	7.5	18	7.5	13	7.5	9	–	–
	MC-22b	45	5.5	22	11	22	15	20	15	18	–	–
40AF	MC-32a	55	7.5	32	15	32	18.5	28	18.5	20	22	17
40AF	MC-40a	60	11	40	18.5	40	22	32	22	23	22	17
65AF	MC-50a	100	15	55	22	50	30	43	30	28	30	23
65AF	MC-65a	115	18.5	65	30	65	33	60	33	35	30	23
100AF	MC-75a	125	22	75	37	75	37	64	37	42	37	28
	MC-85a	135	25	85	45	85	45	75	45	45	37	28
	MC-100a	160	30	105	55	105	55	85	55	65	37	28
150AF	MC-130a	200	37	130	60	130	60	90	55	60	75	50
150AF	MC-150a	250	45	150	75	150	70	100	55	60	75	50
225AF	MC-185a	300	55	185	90	185	110	180	110	120	132	90
225AF	MC-225a	350	75	225	132	225	132	200	140	150	132	90
400AF	MC-265a	400	80	265	147	265	147	225	160	185	147	105
	MC-330a	500	90	330	160	330	160	280	200	220	147	105
	MC-400a	520	125	400	200	400	225	350	250	300	147	105
800AF	MC-500a	700	147	500	265	500	265	400	300	380	280	220
	MC-630a	900	190	630	330	630	330	500	400	420	280	220
	MC-800a	1050	220	800	440	800	500	720	500	630	280	220
1260AF	MC-1260a	1260	–	–	–	–	–	–	–	–	–	–
2650AF	MC-1400a	1400	290	860	550	860	–	–	800	800	–	–
	MC-1700a	1700	310	1050	700	1050	–	–	1000	950	–	–
	MC-2100a	2100	–	–	900	1450	–	–	–	–	–	–
	MC-2650a	2650	–	–	900	1450	–	–	–	–	–	–

Downloads

Title	Categories	Date	Content	hf:doc_categories	hf:doc_tags
Amended DOC (GTH(K) TOR)	Certification	August 5, 2021	3+pole+GTH(K)+DOC+(Amendment)	certification	ms panel-control
[Metasol MS] Contactor Overload Catalog	Catalog	September 25, 2020	[Metasol+MS}_Catalog_EN_202009	catalog	ms
[MS] Mini-MS Contactor Catalog	Catalog	July 22, 2020	[Mini+MS]_Catalog_EN_202007	catalog	ms panel-control
[Device] UL Electric Products_Catalog_EN_202004	Catalog	May 14, 2020	[Device]+UL+Electric+Products_Catalog_EN_202004	catalog	acb dc empr mcb mccb mms ms panel-control power-distribution relay vcb
[MC] 3D CAD Data for Metasol Contactors and TOR	CAD Data	November 20, 2018	MC18AF_40AF MC65AF_400AF MC-800AF MT+3D+CAD	cad-data	ms panel-control
[MC] Coil Change Process for MC/MR Contactor	Technical Data	December 1, 2016	LSIS+MC+Contactor+Coil+Change+Bulletin+Rev+B	technical-data	ms panel-control
[MC] Metasol MC CAD file (Capacitor contactor)	CAD Data	March 14, 2014	Dimension_Metasol+Capacitor+contactor	cad-data	ms panel-control
[MS] Metasol contactor & Relay for Nuclear power plant	Catalog	March 7, 2014	Nu_Metasol+MC_E_1307	catalog	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Marine classification – GL,DNV	Certification	March 7, 2014	MS_GMC(D)_DNV MS_GMC-100_150_GL	certification	ms panel-control
Amended DOC (GMC contactors)	Certification	March 7, 2014	3+pole+GMC+DOC+(Amendment)	certification	ms panel-control
Amended DOC documents (GM_ series starters)	Certification	March 7, 2014	3+pole+GM_starters+DOC+(Amendment)	certification	ms panel-control
[MS]Metasol MS CAD3	CAD Data	March 7, 2014	.+MT-12	cad-data	ms panel-control
[MS]Metasol MS CAD	CAD Data	March 7, 2014	Dimensions_Metasol+(MC-6a_150a) 2.+MC-185a_800a 6.+MT_UZ_Metasol_TOR 5.+MT_150_800 4.+MT_32_95 MC(185a-400a)L MC(_150a)L	cad-data	ms panel-control
[MS] Meta-MEC Series Contactors & TOR CAD DATA (2)	CAD Data	March 7, 2014	GMC-P2_1	cad-data	ms panel-control
Amended Electrical lifetime curve for GMC	Technical Data	March 7, 2014	GMC-E-LifetimeCurve	technical-data	ms panel-control
Coil characteristic data for GMC Contactor	Technical Data	March 7, 2014	COIL_CHARACTERISTICS(GMCGMD+revised)	technical-data	ms panel-control
CB Test Certificate (GMC9~85)	Certification	March 7, 2014	GMC32_40_CB GMC50-85_CB GMC9_22_CB	certification	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Certification – TUV	Certification	March 7, 2014	COC_TUV_GMC100-125 COC_TUV_GMC180-220 COC_TUV_GMC300-400 COC_TUV_GMC600-800	certification	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Certification	Certification	March 7, 2014	GMC100-800 GMC-100-800(4) GMC-10P2_40P2 GMC-150 GMC-150R	certification	ms panel-control
Definition of Utilization Category	Technical Data	March 7, 2014	Category+	technical-data	ms panel-control
Coil characteristic data for GMC-9 ~ GMC-85	Technical Data	March 7, 2014	GMC+Coil+character	technical-data	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Certification – GOST, PSE	Certification	March 7, 2014	GMC_GMD_GMPpdf GMC-100 GMC-200 GMC-400 GMC-800 GMC-9-85_GTH(K)_22-85_GMR4-8 GMW-22B GMW-40B GMW-85B	certification	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Marine classification -KR, LR, NK, BV, ABS	Certification	March 7, 2014	GMC(D)-9R-85R MS_GMC(D)_ABS GMC-9-800 GTH(K) GTH(K)-100 GTH(K)100-600 GTH(K)-12M GTH(K)-150 GTH(K)-400 GTH(K)-600 GTH(K)-85(3)	certification	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Certification – CE	Certification	March 7, 2014	GMC(D)9-22 GMC(D)-9-800 GMC(D)9-85 GMC(D)-9-85(4) GMC(D)-9L-85L GMS-9-85	certification	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Certification – cUL	Certification	March 7, 2014	GMC(D)-9_85(UL) GMC-100_800(UL) GMD-50a+85a_UL GMR-4_8(UL) GTH(K)-100_600(UL) GTK-22_85(UL)	certification	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Mini contactor certification	Certification	March 7, 2014	GMC(D)-6M_9M_12M_16M GMC(D)-6M-16M GMC+MiNi AU-M MS_GMC(D)_DNV	certification	ms panel-control
How to assemble Mechanical Interlock for Mini MC (AR-12M)	Manual	March 7, 2014	AR-12M+Assemble	manual	ms panel-control
[MS]Meta-MEC Series Contactors & TOR Certification – CCC (1)	Certification	March 7, 2014	GMC(D)100-125 GMC(D)150 GMC(D)32-40 GMC(D)50-85 GMC(D)9-800(4)_CB GMC-180-220 GMC-300-400 GMC-600-800 GMR-4_6_8 GTH(K)-100(3) GTH(K)150(3) GTH(K)-22 GTH(K)-220 GTH(K)-40	certification	ms panel-control
Derating of Ith according to temperature (GMC contactor)	Technical Data	March 7, 2014	AC1_Derating-Temperature	technical-data	ms panel-control
[MS]Metasol Series Technical Manual (eng.)	Technical Data	March 7, 2014	Metasol_MS_Technical_140128	technical-data	ms panel-control
[MS] Metasol MS 4P CAD Data	CAD Data	March 7, 2014	MC4P(100a-800a)(3) MC4P(6a_85a)(1)	cad-data	ms panel-control
[MS] Metasol Series MS 3D CAD data	CAD Data	March 7, 2014	MC18a_40a MC65_400	cad-data	ms panel-control
[MS] Meta-MEC Series Contactors & Overload Relays Catalog (eng.)	Catalog	March 7, 2014	MC	catalog	ms panel-control
How to assemble the Mini MC to the MMS	Manual	March 7, 2014	manual_MINI+MS Mini+MC-MMS	manual	ms panel-control
[MS] Metasol(Contactors & TOR) Certification (International Marine)	Certification	March 7, 2014	KR_Metasol_MC_MT DNV_MC_MT ABS_MR GL_MR bv BV_MC_MT NK_Metasol+MC_MT RINA_MC_MT	certification	ms panel-control
CB Test Certificate for Electronic Motor Protection Relay (GMP)	Certification	March 6, 2014	GMP22-40(3)_CB	certification	gmp ms panel-control
Characteristics of GMC coil	Technical Data	March 6, 2014	GMC9_40+Coil+Characteristics	technical-data	ms panel-control
Magnetic contactor Selection table for auto-transformer starter	Technical Data	March 6, 2014	Control+of+motor+starting+current+by+using+auto-TR1	technical-data	ms panel-control
Instruction Manual (EMPR: GMP_Definite time type)	Manual	March 6, 2014	EMPR+Manual_GMP-Definite+Type	manual	gmp ms panel-control
Instruction Manual (DMPR)	Manual	March 6, 2014	EMPR+Manual_DMP+Type	manual	ms panel-control
Manual for Electronic Delay Timer (AT-12M)	Manual	March 6, 2014	E_Timer_Manual	manual	ms panel-control
[MC] Contactor Screws and Lugs Explained	Technical Data	January 6, 2014		technical-data	ms panel-control
