Susol UL MCCB

Susol UL Molded Case Circuit Breaker

Molded Case Circuit Breaker/Molded Case Switch
Molded case circuit breaker with UL Certification
ㅇ Rated current: 15~1200A
ㅇ Breaking capacity (Icu): 25~100kA
ㅇ Service breaking capacity (Ics): 100%

Features

Description

Download

Features

Susol UL MCCB
  • Series : UTE, UTS
  • AF : 100AF, 150AF, 250AF, 400AF, 600AF, 800AF, 1200AF
  • Pole: 2P, 3P
  • Trip unit
    • Thermal magnetic trip unit : FTU, FMU, ATU, MCP
    • Electronic trip unit : ETS, ETM, OCR
  • standards :
    • UL489, CSA
    • IEC 60947-2 CB
    • Class 1E for Nuclear power plant
Susol UL MCS
  • Series : UTE, UTS
  • AF : 100AF, 150AF, 250AF, 400AF, 600AF, 800AF, 1200AF
  • Pole: 2P, 3P
  • standards :
    • UL489, CSA
    • IEC 60947-2 CB

Description

Type 100AF 150AF 250AF 400AF 600AF 800AF 1200AF
E UTE100E
25kA
N UTE100N
35kA
UTS150N
35kA
UTS250N
35kA
UTS400N
35kA
UTS600N
35kA
UTS800N
35kA
UTS1200N
35kA
H UTE100H
65kA
UTS150H
65kA
UTS250H
65kA
UTS400H
65kA
UTS600H
65kA
UTS800H
65kA
UTS1200H
65kA
P UTS1200P
50kA
L UTS150L
100kA
UTS250L
100kA
UTS400L
100kA
UTS600L
100kA
UTS800L
100kA
UTS1200L
100kA

Downloads

TitleCategoriesDateContentLinkdoc_categories_hfilterdoc_tags_hfilter
[Susol UL MCCB] Susol UL MCCB CatalogNovember 29, 2021

Susol UL MCCB_Catalog_EN_202110

catalogmccb panel-control power-distribution
[MCCB] UL MCCB Installation instructionsAugust 26, 2021

Manual_150_250_E_11

Manual_400_600AF_E_12

manualmccb panel-control
[MCCB,ACB] SKM Library Susol MCCB, ACB UL_Software_SW_EN_202002February 25, 2021

[MCCB,ACB]+Susol+MCCB,+ACB+UL_Software_SW_EN_202002+(1)

softwareacb mccb power-distribution
[MCCB] Susol UL MCCB CatalogOctober 30, 2020

Susol+UL+MCCB_Catalog_EN_020210_H

catalogmccb power-distribution
[MCCB] Susol UL MCCB UL, CE CertificatesSeptember 30, 2020

Susol+MCCB_CE_2020.04.23

certificationmccb panel-control
[Susol UL891] UL891 SWGR Solution_Catalog_EN_202004May 14, 2020

[Susol+UL+MCCB]+UL891+SWGR+Solution_Catalog_EN_202004

catalogmccb power-distribution
[Device] UL Electric Products_Catalog_EN_202004May 14, 2020

[Device]+UL+Electric+Products_Catalog_EN_202004

catalogacb dc empr mcb mccb mms ms panel-control power-distribution relay vcb
[MCCB] Susol UL 891 Switchboard Solution 3D CAD filesFebruary 11, 2020

[Susol+UL+MCCB]+UL+891+SWGR+Solution_CAD_EN_202002

cad-datamccb power-distribution
